The CS X-Ray Barrier Cavity Slider door system is designed for use in isotope areas or where diagnostic x-ray apparatus is used. Many doors to x-ray areas are larger than standard and are heavy to operate due to their lead content. A sliding door is far easier to manage - if the door is really big and heavy it can be fully automated.

The cavity pocket has lead shielding custom fitted to all the jambs. Couple this with the CS X-RayBarrier sliding timber door leaf to make a complete system. Door must meet minimum barrier requirements as specified by the consulting engineer.

Details
  • Category
    Cavity Slider Doors
  • Range
    CS Cavity Sliders
  • Brand
    CS Cavity Sliders
  • Designer
    CS Cavity Sliders
  • Year
    2023
  • Warranty
    10 years
General
  • Country of origin
    New Zealand
  • Type of use
    Commercial
  • Installation
    Professional installation recommended
Features
  • Supplied with aluminium jambs in order to accommodate the lead shielding.
  • Modified closing jamb provides an overlap between the wall shielding and the lead lining of the door.
  • Sliding door is easier to manage than a heavy hinged door
  • Large heavy doors can be fully automated.
  • Made to specification up to a maximum door size of 2.4sqm (2400 x 1000mm)
  • Cavity pocket has lead shielding custom fitted to all the jambs.
Specifications
  • Max. Size: Custom sizes up to 2700h x 1200w per door
  • Max. Weight: 240kg per door
  • Wall Framing: 90mm
  • Wall Linings: 10mm, 13mm, other
