High-speed spiral door EFA-SST® Classic
Everything revolves around. Copied a thousand times, yet still unequalled. The tried and tested fundamental principle of EFAFLEX high-speed spiral doors remains unbeatable! The door blade is not rolled up on a shaft, but is guided into the EFAFLEX spiral instead, saving space and keeping it in distance.
- CategoryCommercial Doors
- RangeS Series
- BrandEFAFLEX
- DesignerEFAFLEX
- InstallationProfessional installation required
- AssemblyProfessional assembly required
EFA-SST® Classic at a glance:
- Aluminium laths double-walled
- Opening up to 2.0 m/s
- Closing up to 1.0 m/s
- Highest wind load capacity
- Top safety devices
- Up to 250,000 operating cycles p.a.
- Standard sizes of up to w=8,000 mm, h=7,000 mm
EFA-SST® Classic meets all requirement
The EFA-SST® Classic high-speed spiral door is an extremely fast, safe and reliable exterior door. The door panel consists of double wall aluminium laths, thermally separated profiles provide (on request) for the best in heat insulation. Any required light entry will be constructed as necessary from multi-clearview laths of acrylglas (SAN). An additional locking device guarantees a very high degree of security against burglary. The widest range of equipment and extensive accessories distinguish the high-speed spiral door as the model for the today’s door technology.
Door safety that sets standards
Spiral doors meet all standards: moving parts are carefully clad to ensure the best possible protection against infiltration and efficient finger trap protection. All doors are equipped with a stabilising device for weight compensation as standard: A tension spring mechanism, which automatically pulls the door blade up if, for example, the emergency hand lever is activated in a power cut, is installed in the side frames. The door is protected at closing level via a contact bar or an optoelectronic system, which is fully integrated into the side frames, and thus protected. The EFA-TLG® produces an infrared light grid measuring a maximum of 2.5 m high installed directly in the door closing line.
Oval spiral and low-header design
EFAFLEX provides high-speed spiral doors of various different designs. The circular spiral is the standard solution, and also boasts the fastest opening/closing times. If you only have limited space above the door, then you have two space-saving variants to choose from for many door types in the S Series. Oval spiral and low header.
Versatile use
High-speed spiral doors are always an intelligent solution. Diverse models are available, whether it’s an entrance and exit door for underground garages, a low-lintel version or if fully ventilated instead of standard laths are to be used in the design. And if colour is an issue, almost all RAL colours are available, e.g. your company colour.
Low-wear door pane
Power is transmitted through strap hinges with protected rollers on both sides. A connection shaft ensures synchronization. All laths are individually screwed to the strap hinge for free movement preventing transmission tension within the door panel Rubber sections link the laths together with a „clip“ technique, making them weatherresistant. This is why individual laths can be quickly and easily.
