Integrated - Series 9
Right Hinge. A slim profile, perfect for compact kitchens, or pair with other Integrated models for generous chilled and frozen storage.*Customise with your own kitchen cabinetry or purchase our stainless steel door panel accessory.

Perfect Fit
These models fit flush, with only 4mm gaps around them and no visible hinges or grilles. Our Integrated models can be seamlessly hidden behind your cabinetry, or you can purchase our stainless steel door panel.
Flush fit design with 4mm gaps and custom height installation

Internal Water Dispenser And Ice Maker
Both the water dispenser and ice maker are located inside this Integrated model, leaving an uninterrupted exterior that blends in seamlessly with surrounding cabinetry. The slimline water dispenser is flush fit in order to maximise internal storage space, with a temperature-controlled flow and an angled water delivery to reduce drips and spills.
Convenient access to fresh, chilled water and ice with internal water dispenser and ice maker

Mix & Match
These modular refrigerators and freezers can be mixed and matched, with different sizes and finishes. Installed side by side or individually throughout the kitchen, you can create a cooling solution to suit your lifestyle. Customise with your own kitchen cabinetry and handles, or purchase our stainless steel door panel and handle options.
Easy-to-use touch-control panel and Wi-Fi capability

Clever Energy
ActiveSmart Foodcare learns how you live. It is technology that understands how you use your refrigerator and adjusts temperature, airflow and humidity inside to help keep food fresher for longer.

Flexible Storage
Designed to make it simple for you to store, access and remove food, this refrigerator includes LED-lit adjustable cantilevered shelving and full extension bins in the freezer.

Simple Installation
Our Integrated products are easy to install, whether you are renovating your kitchen or designing a new one. Adjustable front and rear feet allow for uneven floors alongside adjustable door panels that can be customised to match your kitchen. These models are designed to easily slide into place as separate units - a perfect fit for European design kitchens.

Ease Of Use
Using the intuitive touch-sensitive control panel, you can easily adjust the temperature to suit. Beautiful to use, the door is family safe with a soft-close mechanism.

Details
  • Category
    Fridges & Freezers
  • Range
    Fisher & Paykel
  • Brand
    Fisher & Paykel
Specifications

CAPACITY:

  • Volume: 303L
  • Volume freezer: 123L
  • Volume refrigerator: 180L

CONSUMPTION:

  • Energy rating: 5 star
  • Energy usage: 244kWh/year

INSTALLATION DIMENSIONS:

  • Minimum inside width of cabinetry frame: 600mm
  • Minimum internal depth of cabinetry: 600mm
  • Minimum internal height of cabinetry: 1880mm

POWER REQUIREMENTS:

  • Rated current: 10A
  • Supply frequency: 50Hz
  • Supply voltage: 230V

PRODUCT DIMENSIONS:

  • Depth: 576mm
  • Height: 1870mm
  • Width: 592mm

WARRANTY:

  • Parts and labour: 2 years
  • Sealed system parts only: 5 years
Features

FEATURES:

  • Adjustable door shelves: 4
  • Adjustable glass cantilevered shelves
  • Covered door shelves: 1
  • Door alarm
  • Internal water dispenser
  • LED bin lighting
  • LED ceiling lighting
  • LED side lighting
  • SmartTouch control panel
  • Stackable bottle holders: 2
  • Water tank capacity: 1L
  • Wi-Fi connectivity

FREEZER FEATURES:

  • Automatic ice maker
  • Bottle chill
  • Door alarm
  • Fast freeze
  • Freezer bins: 3
  • Ice Boost
  • Ice making rate per day: 1kg
  • LED bin lighting
  • LED ceiling lighting
  • LED side lighting

PERFORMANCE:

  • ActiveSmart Foodcare
  • Adaptive defrost
  • Dual evaporator
  • Frost free
  • Humidity control system
  • Inverter controlled compressor
  • Sabbath mode
Accessories

ACCESSORIES:

  • Hinge change (from right hinge to left hinge)

ACCESSORIES (SOLD SEPARATELY):

  • Door panel set stainless steel: RD6019BR (right hinge), RD6019BL (left hinge)
  • Handle kit Contemporary round, aluminium: AHSRDB19
  • Handle kit Contemporary square fine, aluminium: AHD5RDB19
  • Handle kit Contemporary square fine, black: AHD5RDB19B
  • Handle kit Professional round flush: AHP3RDB19
  • Joiner kit: AJRS19LR
  • Toe kick stainless steel 1200mm: AKRS12010
  • Toe kick stainless steel 1800mm: AKRS18010
  • Toe kick stainless steel 600mm: AKRS06010
  • Water filter replacement: 847200
SKU: 26200
