E-zone | Cyclone Resistant Glass

Glass

E-zone® Cyclone Resistant Glass offers all the protection and peace of mind as StormShield®, with the added benefit of moderating Solar Heat Gain.

The pyrolitic process used in the manufacture of E-zone cyclone resistant glass embeds invisible heat-reflective materials into the glass. This allows light to enter, but reflects much of the inbound heat, increasing comfort. Conversely in cool climates we can configure E-zone to maximize heat retention.

Hydrostatic pressure testing has demonstrated that E-zone can provide substantially superior flood resistance when installed in a certified flood resistant frame compared to standard laminates.

Details
  • Category
    Safety Glass
  • Range
    Storm Glass
  • Brand
    Glasshape
  • Designer
    Glasshape
Specifications

E-zone Glass Features & Benefits

  • Decreased solar heat gain provides a cooler environment for improved working conditions and comfort
  • Retains high levels of visual light transmission
  • Reduce HVAC requirements and subsequent positive impact on systems size requirements
  • ‘Always on’ – no taking temporary covers on and off
  • Superior building aesthetics and unobstructed visibility
  • Larger windows can be designed
  • Withstands extreme pressure >12kPa, wind gusts >500 km/h
  • Expedited recovery post-event
  • Evaluated at the world class James Cook University cyclone testing station with excellent results
  • Standard dimensions up to 3900mm x 2440mm
  • 2D curves (single radius and single axis)
  • AS/NZS 1170.2:2011
  • AS/NZS 1288
  • Certified in wide range of commonly available cyclone rated framing systems including Alspec, Capral, Alutech, AWS and Wintec

NB: Debris Impact Resistant certified framing system required

Scope of use

Glasshape has recently improved its E-zone Glass product range and we are now offering combined product solutions for both Region C&D, E-zone Glass Ultra & E-zone Glass Extreme. These two new product variants provide multifaceted enhancements to combat the conditions experienced in both regions, E-zone Glass Ultra for impact resistance up to 39m/s & E-zone Glass Extreme for impacts up to 44m/s. E-zone Glass products are the only available annealed laminated product solution for Cyclone Resistance that can be cut and processed from stock sheets and available from our local stockists.

Get in touch
Visit Website

About the
Seller

Delivering Bent & Specialist Glass with Excellence.

Glasshape®, established in 1986, is a leading innovator, designer and manufacturer of bent, tempered (toughened), laminated and digital ceramic print specialty glass. Family owned and based in Auckland, New Zealand, Glasshapes philosophy of growth through innovation, ingenuity and customer service sees it deliver best-in-class glazing solutions in a variety of categories, with notable success in marine, architectural (residential and commercial), cyclonic, high security and heavy machinery projects.

Consistently investing in technology and capacity to meet the increasing demands from architects, designers and their clients, Glasshape® designs and supplies certified bent and flat glass, either monolithic or laminated, for almost any setting. With Australian offices in Perth, Brisbane and Melbourne, and headquartered in Auckland, New Zealand, Glasshape® provides customer centric solutions with an international reach.

Our brands are lauded and respected for the quality and craftsmanship they represent and include DurashieldMarine® marine grade glass, TemperShield® bent toughened glass, AmmoShield® and ArmourShield® attack resistant glass, StormShield® cyclone resistant glass and VisionInk® digitally printed ceramic inks.
