StormShield | Cyclone Glass Solutions

Glass

Specifically developed to resist excessive wind speeds and penetration from flying debris, StormShield cyclone glass is a certified debris impact resistant glazing solution available in multiple thicknesses for different openings throughout cyclone regions C and D in Australia and the Pacific.

Glasshape has recently improved its StormShield product range and we are now offering combined product solutions for both Region C&D, StormShield Ultra & StormShield Extreme. These two new product variants provide multifaceted enhancements to combat the conditions experienced in both regions, StormShield Ultra for impact resistance up to 39m/s & StormShield Extreme for impacts up to 44m/s. StormShield products are the only available annealed laminated product solution for Cyclone Resistance that can be cut and processed from stock sheets and available from our local stockists.

Details
  • Category
    Safety Glass
  • Range
    Storm Glass
  • Brand
    Glasshape
  • Designer
    Glasshape
Specifications

StormShield Features & Benefits

  • ‘Always on’ – no taking temporary covers on and off
  • Improved aesthetics and unobstructed visibility
  • Larger windows can be designed
  • Withstands extreme pressure >12kPa, wind gusts >500 km/h
  • Expedited recovery post-event
  • Evaluated at the world class James Cook University cyclone testing station with excellent results
  • Standard dimensions up to 3900mm x 2440mm
  • 2D curves (single radius and single axis)
  • AS/NZS 1170.2:2011
  • AS/NZS 1288
  • Certified in wide range of commonly available cyclone rated framing systems including Alspec, Capral, Alutech, AWS and Wintec

NB: Debris Impact Resistant certified framing system required

Performance

StormShield uses a specially formulated ultrahigh grade laminate in the manufacturing process, engineered for the glass to expand and contract up to five times its normal rate before breaking, providing maximum protection from wind born debris. The proprietary process allows us to manufacture glass that has better performance ratings from lighter, thinner compositions versus our competitors.

In the event the cyclone glass is damaged by flying storm debris, StormShield remains weather-tight without tearing or breaching, and the glass, though shattered, will remain adhered to the laminate eliminating the hazard of glass shards flying through the room.

While most cyclone-rated glazing is available in only a single standard thickness, StormShield comes in multiple thicknesses each for region C and region D, meaning larger window spans can be designed to take advantage of light and open space than what would have otherwise been possible.

Get in touch
Visit Website

About the
Seller

Delivering Bent & Specialist Glass with Excellence.

Glasshape®, established in 1986, is a leading innovator, designer and manufacturer of bent, tempered (toughened), laminated and digital ceramic print specialty glass. Family owned and based in Auckland, New Zealand, Glasshapes philosophy of growth through innovation, ingenuity and customer service sees it deliver best-in-class glazing solutions in a variety of categories, with notable success in marine, architectural (residential and commercial), cyclonic, high security and heavy machinery projects.

Consistently investing in technology and capacity to meet the increasing demands from architects, designers and their clients, Glasshape® designs and supplies certified bent and flat glass, either monolithic or laminated, for almost any setting. With Australian offices in Perth, Brisbane and Melbourne, and headquartered in Auckland, New Zealand, Glasshape® provides customer centric solutions with an international reach.

Our brands are lauded and respected for the quality and craftsmanship they represent and include DurashieldMarine® marine grade glass, TemperShield® bent toughened glass, AmmoShield® and ArmourShield® attack resistant glass, StormShield® cyclone resistant glass and VisionInk® digitally printed ceramic inks.
