Induction Cooktop, 83cm, 4 Zones with Integrated Ventilation

Not Applicable
Not Applicable
Not Applicable

Minimal - Series 9
A true two-in-one appliance, this cooktop combines the precision of induction cooking with powerful extraction in one seamless, stylish cooktop. Seamless kitchen integration, without the need for overhead ventilation


Seamless Integration
Offering true design freedom, this cooktop can be placed anywhere - eliminating the need for bulky overhead ventilation and helping to create a seamless flow between kitchen and living spaces. Installed raised or flush, it's perfect for islands, or homes with high ceilings.
Four cooking zones, including a simple pairing of two zones to create a SmartZone


Elegant Design
The subtle black glass and durable matte black detailing blends elegance with durability. With premium styling, these cooktops seamlessly blend with other appliances for a cohesive, considered kitchen design.
With nine fan speeds plus a boost, select the perfect extraction rate for your cooking


Precise Control
Fisher & Paykel induction cooktops offer extremely accurate temperature control from very high to very low heat, so you can sear, saute and temper like a pro. Touch&Slide controls react immediately when you adjust the temperature, so you can go from a boil to a simmer in seconds.
Minimal style, sleek black glass finish to suit any kitchen design


Effective Extraction
Designed for busy homes, the integrated ventilation works effectively and unobtrusively in the background. Featuring nine fan speeds, plus a boost function, for quickly removing odours and steam.

Safety Of Induction
Induction cooktops only start heating your pot or pan once you've placed it on the surface and stop as soon as you remove it - so they are safer for everyone.

Ease Of Use
Designed for simple removal, the grease filter tray effectively captures spills, while the single glass cooking surface can be easily wiped clean. A flush ventilation grille allows pots to effortlessly slide across the cooktop surface.

Superior Efficiency
Less heat is wasted during induction cooking because only the cookware is heated, not the cooktop surface. This makes induction cooking more energy-efficient than electric or gas cooktops.

Details
  • Category
    Cooktops
  • Brand
    Fisher & Paykel
  • Warranty
    2 years
Specifications

CLEANING:

  • Dishwasher-safe grease filter
  • The flat easy clean glass surface
  • Flush grille
  • Pan detection system

CONTROLS:

  • Auto cut-off timer for each zone
  • Minute timer
  • Soft-touch electronic controls
  • Touch and slide controls

DOWNDRAFT PERFORMANCE:

  • Air outlet size: 220mm W x 90 mm H
  • Air speeds: 9 + boost
  • Ducted externally
  • Ducting direction: Side, Rear
  • Maximum airflow (Boost): 660m³/hr
  • Maximum airflow (Level 9): 623m³/hr
  • Maximum noise level (Boost): 70dBA
  • Maximum noise level (Level 9): 69dBA
  • Minimum air flow: 192m³/hr
  • Minimum noise level: 38dBA
  • Motor type

DUCTING ACCESSORIES (OPTIONAL):

  • Duct 1m Connector 222x89: 82389 D1-C-222-89
  • Ducting adaptor: 82392 DA-219-98-150
  • Elbow 90° horizontal 222x89: 82390 E90-H-222-89
  • Elbow 90° vertical 222x89: 82391 E90-V-222-89

PERFORMANCE:

  • Gentle heat
  • Heat settings: 9
  • Induction cooking technology
  • Pause function
  • PowerBoost
  • SmartZone

POWER REQUIREMENTS:

  • Electrical connection: Terminal block
  • Maximum power: 7.4kW
  • Supply frequency: 60Hz
  • Supply voltage: 220 - 240V

PRODUCT DIMENSIONS:

  • Depth: 515mm
  • Height: 218mm
  • Width: 830mm

SAFETY:

  • Keylock
  • Pan detection system
  • Safety time out
  • Surface hot indicators

WARRANTY:

  • Parts and labour: 2 years

ZONE RATINGS:

  • Left front: 2100W
  • Left front zone (PowerBoost set): 3000W
  • Left rear: 2100W
  • Left rear zone (PowerBoost set): 3000W
  • Right front: 2100W
  • Right front zone (PowerBoost set): 3000W
  • Right rear: 2100W
  • Right rear zone (PowerBoost set): 3000W
  • SmartZone: 3700W

ZONES:

  • Number of elements: 4
Accessories

ACCESSORIES (SOLD SEPARATELY):

  • Recirculation kit: 82236 KRCID834 (optional)
  • Replacement recirculation filter: 50182 FRO-DD (optional)
  • Square grille & butterfly valve for wall exhaust: 82393 DO-G-SS (optional)
SKU: 82228
