Integrated Refrigerator Freezer, 61cm, Ice & Water, Left Hinge

Not Applicable
Not Applicable
Not Applicable

Integrated - Series 11
Left Hinge. A slim profile, perfect for compact kitchens, or pair it with other Integrated models for generous chilled and frozen storage.*Customise with your own kitchen cabinetry or purchase our stainless steel door panel accessory.

Variable Temperature Zone
Create the perfect climate and store each type of food at optimal temperature and humidity with Variable Temperature Zone, reducing food waste due to spoiling. You have the choice of four food modes: Pantry, Fridge, Soft Freeze or Freezer. Use the Max cold feature for periods of high refrigerator or freezer use, or full grocery loads. Keep food fresher for longer by constantly maintaining the ideal temperature with ActiveSmart technology

Pantry Mode
Not everything benefits from cold storage. Pantry Mode (11 to 13C) is the perfect climate to store foods that benefit from a cool, dark place, including bread, many types of fruit, bananas, avocados, tomatoes, nuts, grains and cereals. Create the perfect climate for each type of food with Variable Temperature Zone: choice of four food modes, Pantry, Fridge, Soft Freeze or Freezer.

Soft Freeze Mode
Soft freeze is for food that requires a gentle freeze and quick thawing, perfect for items that will be consumed soon. It allows easy portioning and the ability to heat, cook or serve straight from the compartment, without waiting for it to thaw. Convenient access to fresh, chilled water and ice with internal water dispenser and ice maker.

Internal Water Dispenser And Ice Maker
Both the water dispenser and ice maker are located inside this Integrated model, leaving an uninterrupted exterior that blends in seamlessly with surrounding cabinetry. The slimline water dispenser is flush fit in order to maximise internal storage space, with a temperature-controlled flow and an angled water delivery to capture any drips and spills.

Activesmart Foodcare
ActiveSmart Foodcare learns how you live. It's technology which understands how you use your refrigerator and adjusts temperature, airflow and humidity inside to help keep food fresher for longer.

Complementary Design
Both the 61cm and 76.2cm Integrated Refrigerator Freezers can be installed separately or paired with a Column Refrigerator, Freezer or Wine Column. Customise with your own kitchen cabinetry and handles, or purchase our stainless steel door panel and handle options.

Design Quality
The premium design and finish includes a steel interior lining as well as full extension metal shelf runners for easy access, robust glass shelving and quality hinges designed for daily use.

  • Category
    Fridges & Freezers
  • Brand
    Fisher & Paykel
  • Warranty
    2 years


  • Volume: 342L
  • Volume freezer: 115L
  • Volume refrigerator: 227L


  • Energy rating: 3.5 star
  • Energy usage: 340kWh/year


  • Rated current: 10A
  • Supply frequency: 50Hz
  • Supply voltage: 230V


  • Depth: 610mm
  • Height: 2134mm
  • Width: 603mm


  • Parts and labour: 2 years
  • Sealed system parts only: 5 years


  • Adjustable door shelves: 4
  • Covered door shelves: 1
  • Door alarm Gallon door shelves: 1
  • LED bin lighting
  • LED ceiling lighting
  • LED side lighting
  • SmartTouch interface at counter height Stackable bottle holders: 4
  • Ultra slim water dispenser
  • Wi-Fi connectivity


  • Automatic ice maker
  • Bottle chill
  • Door alarm
  • Door shelves: 1
  • Freezer bins: 2
  • Freezer trays: 1
  • Ice Boost
  • LED bin lighting
  • LED ceiling lighting
  • LED lighting
  • LED side lighting
  • Slide Out Pastry Tray
  • SmartTouch interface at counter height


  • ActiveSmart Foodcare
  • Adaptive defrost
  • Dual evaporator
  • Frost free
  • Humidity control system
  • Inverter controlled compressor
  • Noise emissions: 42dBA
  • Noise emissions class: D
  • Sabbath mode
  • Variable temperature zones: 2


  • Door panel stainless steel Left hinge 610mm: RD6121WLD
  • Door panel stainless steel Right hinge 610mm: RD6121WRD
  • Handle kit Contemporary round, aluminium: AHSRD6121W
  • Handle kit Contemporary square fine, aluminium: AHD5RD6121W
  • Handle kit Contemporary square fine, black: AHD5RD6121WB
  • Handle kit Contemporary square, aluminium: AHD3RD6121W
  • Joiner kit: AJ-RS21LR
  • Matching Replacement Water Filter Model: 847200
  • Toe kick stainless steel 1220mm: AKRS12210
  • Toe kick stainless steel 1372mm: AKRS13710
  • Toe kick stainless steel 1828mm: AKRS18310
  • Toe kick stainless steel 1981mm: AKRS19810
  • Toe kick stainless steel 610mm: AKRS06110
SKU: 25692
