Centor ES2 Framing System

Centor®

Centor ES2 offers joiners a complete framing system, incorporating award-winning hardware and built-in fly screens. Suitable for openings up to 3000mm high and 5800mm wide, all that is needed to complete the system are quality timber door panels.

Details
Specifications

Stainless steel

  • Max. panel weight: 60kg
  • Max. panel height: 3000mm
  • Max. panel width: 1100mm
  • Panel thickness: 38 - 40mm
  • Max. frame size – single screen: 2400 (H) x 3000mm (W), 3000 (H) x 2400mm (W)
  • Max. frame size – double screen: 2400 (H) x 5800mm (W), 3000 (H) x 4800mm (W)

Aluminium

  • Max. panel weight: 40kg
  • Max. panel height: 3000mm
  • Max. panel width: 1000mm
  • Panel thickness: 38 - 40mm
  • Max. frame size – single screen: 2400 (H) x 3000mm (W), 3000 (H) x 2400mm (W)
  • Max. frame size – double screen: 2400 (H) x 5800mm (W), 3000 (H) x 4800mm (W)
Features
  • Top-hung bifold system
  • Outward opening panels
  • Screen configurations:Single: a screen extending from one side of the frame across the entire opening up to 3000mm
    Double: two screens meeting in the middle of the opening up to 5800mm wide
  • Load-balancing technology ensures the screen remains in any chosen position until moved aside
  • Self-feeding mechanism will feed the mesh onto the roll as the screen is retracted if it blows out of the top or bottom track
  • Hardwearing Polyester/PVC mesh can be replaced if required
  • Built-in screens are cycle tested to 50,000 operations with exposure to contaminants such as dirt, sand and plaster
  • Collision tested with a 17kg punching bag!
  • ES2 has been tested to comply with AS 2047-1999 in a NATA certified facility (Test no. AZT0100)
  • 10-year limited warranty on the hardware
  • 5-year limited warranty on the screen
