Shut it® Face Mount Gate Weld-On Badass

The Bolt-On BadAss was designed to be used on gates where welding the hinges to the gate and the end post is not an option. Due to SHUT ITs unique bushing design The Bolt-On BadAsses, like all other SHUT IT gate hinges, produces near frictionless movement with maintenance free usage.

  • Category
    Gate Accessories, Automatic Gates, Security Gates
  • Range
    Shut it®
  • Brand
    D&D Technologies
  • Designer
    D&D Technologies
  • Country of origin
  • Product Code - CI3050
  • Gate Type - Non-Self-Closing
  • Gate Material - Steel/Ornamental Iron
  • Approx Gate Size - 2m H x 3m W - (7ft x 10ft)
  • Gate Frame/Post Shape - Square-to-Square
  • Min Post Size - 38mm+
  • Ideal Gate Gap - 74-86mm
  • Fixing Method - Bolt-On
  • Colour/Finish - Zinc
Scope of use

Gate Application - Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate

  • Opens to 180
  • Achieve gate gaps as small as 1/2" (13mm)
  • Horizontally adjustable to 1/2" (13mm)
  • Both weld-on and bolt-on models available
  • High-temp bearings, safe to powder-coat
  • Load rating per gate: 2,000 lb (900kg)
  • Maximum gate weight: 1,100 lb (500kg)
SKU: CI3050
