VLR 70 S Heat Recovery Ventilation System

By STIEBEL ELTRON
Visit Website

Create a pleasant indoor environment in the home with the VLR 70 S decentralised heat recovery ventilation. Installed in pairs with ducting through the walls, the VLR 70 S has a heat recovery level of up to 92%.

Decentralised ventilation unit with heat recovery for ventilating apartments and small commercial properties.

Contemporary design with a separate programming unit can be used for floor areas up to approx. 100 m2. Axial fan with a rigid fan curve, for use even in areas that are exposed to wind. With efficient aluminium heat exchanger and driving rain-resistant external panel. Straightforward filter replacement using easy to remove fan unit. Fine dust filter available as an accessory. White powder-coated stainless steel external panel. Matt white plastic internal panel. EC fan ensures efficient operation.

Installation in round or square wall outlets with a maximum thickness of 550 mm (550 to 800 mm including telescopic casing available as an accessory). Easily accessible electrical connection on the inside of the fan unit.

Details
  • Category
    Heat Recovery Ventilation
  • Range
    Ventilation
  • Brand
    Stiebel Eltron
Specifications
  • Model number - VLR 70 S Trend
  • Power consumption - 7 W
  • Rated voltage - 24 V
  • Max. current - 0.3 A
  • Air volume flow - 20-70 m3/h
  • Filter class - ePM1 ≥ 50 % (F7) | ISO Coarse > 30 % (G2)
  • Min. outlet aperture diameter - 200 mm
  • Wall thickness - 100 - 300 mm
  • Sound power level - 35 dB(A) at 20 m3/h
  • Height - 285 mm
  • Width - 360 mm
  • Depth - 590 mm
  • Weight - 5.2 kg
  • Up to 92% heat recovery
  • Decentralised ventilation – suitable for new builds and renovations
  • Supplies fresh air from outside to in your home or office
  • Compact fan ensures easy inspection and maintenance
  • Quiet operation
  • Installed in pairs, connect up to 8 units together
