Centor S4 Retractable Insect Screen System

The Centor S4 is designed for large architectural openings where insect protection, uninterrupted views and effortless operation are important.

Ideal for:

• Large sliding doors
• Bi-fold and folding doors
• Multi-panel door systems
• Large window openings
• Indoor-outdoor living areas
• Covered outdoor entertaining areas
• High-end residential homes
• Architectural renovations
• Hospitality and commercial spaces
• Coastal and outdoor-focused living environments

The S4 can be installed to the inside or outside of the opening and is available in multiple configurations to suit different door layouts and architectural requirements.

For projects requiring additional environmental control, S4 can also incorporate blinds for light filtering, blackout and privacy.

• Retractable Insect Screen – Disappears discreetly into the frame when not in use, keeping views open and the architecture uncluttered.
• Fingertip Operation – Centor’s load-balancing technology allows the screen to glide smoothly across the opening with one hand.
• Large Opening Capability – Designed for substantial sliding, folding and architectural door openings.
• Uninterrupted Views – No pleated mesh or sliding panels interrupt the view when the screen is open.
• Secure Mesh Retention – Top and bottom tabs help prevent screen blow-out, even in breezy conditions.
• Fully Retained Screen – The mesh remains securely contained within the frame for effective insect protection.
• Multiple Configurations – Available as single, double, combination, XO and jambless systems.
• Internal or External Installation – Can be installed to suit the architecture and door configuration.
• Customisable Frame – Durable aluminium frames can be powder-coated in a wide range of colours.
• Integrated Blind Options – The S4 system can incorporate light-filtering and blackout blinds for additional privacy and solar control.
• Easy Maintenance – Removable sill cover provides straightforward access for cleaning.
• 5-Year Limited Warranty – Backed by Centor’s 5-year limited warranty.

• System: Retractable insect screen and blind system
• Frame height with insect mesh: 815–4000mm
• Frame height with exterior blind: 815–3200mm
• Frame height with interior blind: 815–3000mm
• Single frame width: 1015–4611mm
• Combination frame width: 1015–4676mm
• Double frame width: 1015–9013mm
• Configurations: Single, Double, Combination, XO/OX and Jambless
• Installation: Internal or external
• Frame: Aluminium
• Frame finish: Powder-coated
• Screen: Multiple mesh options
• Blind: Light-filtering and blackout options
• Operation: Load-balanced, one-handed operation
• Warranty: 5-year limited warranty
• Assembly: Professional installation required
• Origin: Australia

The S4 is available in multiple configurations to accommodate different door layouts, opening sizes and architectural requirements.

Single
A single screen extends from one side of the frame to cover the full opening.

Double
Two screens meet at any point across the opening, providing flexibility for wider openings and different access requirements.

Combination
Different fabric types can be combined within the same system. For example, an insect screen can be positioned on one side while a blind is housed on the other.

XO / OX
A single screen covers a sliding door opening and stops against the door handle, with the opposite jamb integrated into the wall. XO and OX configurations are available to suit the direction of the opening.

Jambless
A single screen operates without an opposing jamb, providing unobstructed access to sliding door and window handles. The jambless configuration can also maintain views through corner fixed-lites.

Screen Mesh Options
Screen mesh is available in different weave styles to provide insect protection without the visual distraction of pleated or sliding screen panels.

Blind Options
The S4 system can incorporate light-filtering and blackout blind fabrics in a range of colours and patterns, providing an integrated solution for privacy and solar control.

Frame Finishes
The aluminium frame can be powder-coated in a wide range of colours to complement the surrounding doors, windows and architecture.

Installation Position
S4 systems can be installed internally or externally. External installations incorporate sill drainage to suit the installation environment.
