HB 1575 510mm Large Flush Pull

Halliday + Baillie

The HB1575 is a continuation of the flush pull story. It’s expansive 510mm x 70mm size gives you the option of a flush finish on pivot or bi-fold doors on a grand scale.

The increased finger grip provides efficient leverage for oversized sliding doors, and is an ideal option for bi-folding, hinge, or pivot doors where a flush fit is preferred.

Due to the additional grip along one edge of the flush pull, all bi-fold/pivot grip flush pulls are handed and need to be ordered as left hand or right hand options.

Please note that due to the increased grip depth of these pulls a minimum door thickness of 38mm is suggested if using in a back to back application on timber doors with nothing else between.

Details
General
  • Country of origin
    New Zealand
  • Care and cleaning
    Easy maintenance
  • Installation
    Professional installation recommended
  • Assembly
    Professional assembly recommended
Scope of use
  • Designed for oversized, heavy, or large-format doors, including sliding, pivot, bi-fold, and hinged doors.
    • Suitable for timber or aluminium doors with sufficient thickness to recess the large body of the pull.
    • Ideal for high-end residential and commercial projects where a large architectural statement pull is required.
    • The offset-grip design makes it suitable for doors needing enhanced leverage and strong user grip.
Features

Material: Solid Brass

Suitable for timber or aluminium doors of suitable thickness. HB1510 timber fixing kit to be ordered separately

For finish options please see our current finishes sheet. Please check with your local Halliday + Baillie representative as not all finishes are available in all regions.

Flush pulls are designed to be mounted with the body within the thickness of the door, and the face plate on the door surface – total projection is 2mm. Fully recessed mounting is possible on timber doors with the appropriate door thickness. Using glue, epoxy or silicone products etc to secure flush pulls to the door is not required or recommended for installation, and may void warrantee.

Specs / Details

Available in both right and left-handed flush pulls – please specify handing for order.

Material : Milled Solid Brass Dimensions : 510 x 70 x 17

Internal grip depth : 15mm Suitable for large timber or aluminium doors.

Available in all standard Halliday + Baillie finishes.

See finishes sheet for further details
