HyperGlide™ Compact High Speed Door
The AUTO MOSSA HYPERGLIDE COMPACT is designed for smaller openings, internal and external applications. This compact design is ideal for food and beverage production facilities. The door blade is constructed from a robust PVC coated woven fabric. Integrated into the door blade is the patented AIRSTRIP system. This rubber AIRSTRIP design allows the door to operate at faster speeds with a smoother operation without compromising other functions. The AIRSTRIP also allows the door to be reinforced for unequaled higher wind loadings while still maintaining fast operating speeds. The door comes standard with a soft bottom edge and knock out / automatic curtain relocation function.
- CategoryRoller Garage Doors, Sectional Garage Doors, Commercial Doors
- RangeHigh Speed Doors
- BrandAuto Mosssa
- Warranty1 year
- Country of originNew Zealand
- Type of useCommercial
- InstallationProfessional installation required
- Standard size up to (W x H)’: 4000 x 3600 mm
- Opening/closing speed up to max.: 2.5 / 0.6 m/s
- Wind resistance: Class 1 - 3 EN 12424
- AirStrip: Standard
- Variable speed drive: Standard
- Control voltage: 24V DC
- Mains connection: PNE 230V, 3L(N)/PE/415V, 50/60 Hz
- 2 x sets of in-line photocells: Standard
- Flexible soft bottom edge: Standard
- Door blade Knock-out capability: Standard
- Top roll cover: Standard
- Motor Cover: Standard
- Curtain colour options: Six standard colours available
Faster
The Hyperglide™ High Speed door will operate at speeds of up to 3.0m/sec on doors up to 4.0m wide and 3.6m high. The new AirStrip™ design enables the door to operate at these speeds without wear on the door blade.
Quieter
The AirStrip™ was designed to combine high speed with quiet and smooth operation. Constructed from a flexible rubber strip, the Airstrip dampens noise and creates a cushioning effect when the door runs at high speeds.
Cleaner
The AirStrip™ feature on the Hyperglide™ separates the layers of the door blade to ensure that the PVC has minimal contact with itself. This will ensure that dirt is not infused into the PVC, protecting the vision panels and preventing surface damage over many thousands of cycles.
Stronger
Many door designs over 4.0m wide struggle to perform in high winds. This is often a result of the track retention systems being under excessive load, or the rigidity of the door blade is not up to the task. The Hyperglide™ AirStrip™ design enables the wind bar system to be greatly strengthened to handle higher wind class up to 6.0m wide x 6.0m high. Increasing the integrity of the wind bars has no impact on the speed or the smoothness of the door operation.
