Max Lite Window

Rylock Windows & Doors
Max Lite Window gallery detail image
Max Lite Window gallery detail image

Rylock Commercial Series Max Lite Windows are endlessly customisable to enhance a home’s architectural style. They are available with a maximum area of 7.5m², as custom raked head (3, 4 or 5-sided configurations), or butt joint windows and can be coupled to other Commercial Series products with a 125mm depth, to suit your project’s individual requirements. Max Lite Windows are glazed in accordance with Australian Standards AS 1288 Glass in Buildings and whilst a large range of options are available, all products are glazed with Grade A Safety Toughened Low-e Double Glazing (Argon Fill) as a standard specification.

Details
  • Category
    Sash Windows
Specifications
  • Max Product Height: 6000mm ⁽¹⁾
  • Max Product Width: 6000mm ⁽¹⁾
  • Glazing Capacity: 32mm - 36.76mm
  • Wind Rating: N1 - N3
  • Air Infiltration: 0.1 L/s.m²
  • Water Resistance: 600 Pa

⁽¹⁾ Sash / panel height and width are relative measures and must comply with maximum area and mass limitations.

  • Uw Value: 2.0 ⁽²⁾
  • SHGCw Value: 0.21 - 0.53 ⁽²⁾

⁽²⁾ Energy results are product and size specific. As product sizes reduce, energy values increase. Custom energy results will be supplied with your Quotation - Sales Order.

Commercial Series – 125mm Frame

Max Lite Windows introduce sunlight and landscapes at maximum sizes to provide an exceptional architectural feature.

Installation Guide

The most vital aspect of correct function – is correct installation.

It is recommended that the manufacturer’s specification is always followed as improper installation can lead to air infiltration, moisture and poor overall performance.

Rylock has detailed Typical Building-In Details for four common wall types to assist in the best practice installation of product:

  • Linea Board
  • Hebel PowerPanel
  • Brick Veneer; and
  • Double Brick

Projects featuring Max Lite Window

About the
Seller

For more than 40 years, Rylock has locally manufactured high performance, double glazed windows and doors for Australian conditions. Whilst a lot has changed, we continue to design our products in-house and utilise quality materials and technical expertise.

Our state-of-the-art manufacturing plant includes several CNC (computer numeric controlled) machines for precision repetition machining, resulting in improved quality control and health & safety standards. Today, our experienced team continue to ensure every product epitomises our commitment to craftsmanship, innovation and design.
