Servery Window
Rylock Commercial Series Servery Windows promote ventilation and draw the outside in, for a sense of connection when entertaining between indoor and outdoor spaces. The (openable) sash range of movement is controlled by a black flush pull handle and a stainless steel and rubber panel stop, which ensures there is no damage to the frame when the sash is opened. Sash seals provide resistance against air and water infiltration for exceptional results in AS 2047 Windows and External Glazed Doors compliance testing. Servery Windows are glazed in accordance with AS 1288 Glass in Buildings and whilst a large range of options are available, all products are glazed with Grade A Safety Toughened Low-e Double Glazing (Argon Fill) as a standard specification.
- CategorySash Windows
- Max Product Height: 2150mm
- Max Product Width: 6000mm
- Max Sash Height: 2150mm ⁽¹⁾
- Max Sash Width: 2400mm ⁽¹⁾
- Glazing Capacity: 4mm - 24.76mm
- Wind Rating: N1 - N3
- Air Infiltration: 0.5 L/s.m²
- Water Resistance: 360 Pa
⁽¹⁾ Sash / panel height and width are relative measures and must comply with maximum area and mass limitations.
- Uw Value: 2.8 ⁽²⁾
- SHGCw Value: 0.22 - 0.49 ⁽²⁾
⁽²⁾ Energy results are product and size specific. As product sizes reduce, energy values increase. Custom energy results will be supplied with your Quotation - Sales Order.
Servery Windows enhance a home’s indoor and outdoor connection for effortless entertaining when passing food and drinks between living spaces.
Servery Windows feature a low-profile recessed flush pull handle which easily controls the sash range of movement. The handle features rounded corners for a classic design aesthetic and an integrated key lock.
Available in black, silver and white colour with stainless steel lock.
The most vital aspect of correct function – is correct installation.
It is recommended that the manufacturer’s specification is always followed as improper installation can lead to air infiltration, moisture and poor overall performance.
Rylock has detailed Typical Building-In Details for four common wall types to assist in the best practice installation of product:
- Linea Board
- Hebel PowerPanel
- Brick Veneer; and
- Double Brick
