Projecting Sash Window
Rylock Commercial Series Projecting Sash Windows offer ventilation through an unobstructed view with no flyscreen. The product is fitted with two multi-point handle latches (available in black, silver and white) that are rotated 90 degrees to unlock the sash with a range of motion that is controlled by four stainless steel stays. This allows the sash to slide forward by 125mm for a narrow perimeter of ventilation.
Dual sash seals fitted to the sash and frame ensure resistance against air and water infiltration for exceptional results in AS 2047 Windows and External Glazed Doors compliance testing. Projecting Sash Windows are glazed in accordance with AS 1288 Glass in Buildings and whilst a large range of options are available, all products are glazed with Grade A Safety Toughened Low-e Double Glazing (Argon Fill) as a standard specification.
- CategorySash Windows
- Max Product Height: 1500mm ⁽¹⁾
- Max Product Width: 1500mm ⁽¹⁾
- Glazing Capacity: 4mm - 24.76mm
- Wind Rating: N1 - N3
- Air Infiltration: 0.1 L/s.m²
- Water Resistance: 600 Pa
⁽¹⁾ Sash / panel height and width are relative measures and must comply with maximum area and mass limitations.
- Uw Value: 2.9 ⁽²⁾
- SHGCw Value: 0.23 - 0.48 ⁽²⁾
⁽²⁾ Energy results are product and size specific. As product sizes reduce, energy values increase. Custom energy results will be supplied with your Quotation - Sales Order.
Projecting Sash Windows provide a revolutionary method of delivering ventilation and unobstructed views with a sash that slides forward, parallel to the outer frame.
Projecting Sash Windows are fitted with two multi-point latches that are rotated 90° to unlock the sash for a narrow perimeter of ventilation.
Projecting Sash Window handle hardware is available in black, silver and white.
The most vital aspect of correct function – is correct installation.
It is recommended that the manufacturer’s specification is always followed as improper installation can lead to air infiltration, moisture and poor overall performance.
Rylock has detailed Typical Building-In Details for four common wall types to assist in the best practice installation of product:
- Linea Board
- Hebel PowerPanel
- Brick Veneer; and
- Double Brick
