PixelARC - Power Plus Wireless Charging
PixelARC is a premium commercial grade wireless fast charger with an integrated standard mains socket plus power delivery USB fast charging in an ultra-compact power module. With four power options in one PixelARC is the ultimate in power and mobile charging options, perfect for work and education spaces.
Providing a powerful 10W of wireless charging power PixelARC is one of the fastest wireless chargers on the market. PixelARC will fast charge wireless-enabled phones on contact with a power range of up to 8mm to accommodate phone cases. PixelARC is Qi Certified for multi-device compatibility and is specifically designed for fast charging Apple and Samsung phones.
- CategoryOffice Accessories
- Warranty2 years
Configuration
- In addition to the 10W Qi-compatible wireless charger, pixelARC’s socket aperture can be configured with:An Australian or any AC power socket from our 42mm international range
Class-leading TUF-PD (25W) USB fast charger
TUF-HP (72W) USB fast charger with under-desk PSU
Input / Output Power
- Output Power: 10W (DC5V 1A / 9V 1.1A)
- Input Power (Charger): 15W Max (DC5V 2A / 9V 1.67A)
Construction
- High-strength fire-retardant polycarbonate
Size Options
- Surface Cut Out: Ø80 mm
Colour Options
- Black or White
Power Cord Options
- PixelARC may be ordered either hardwired to:Mains AC plug to match AC socket type, or
Male Wieland GST18 connector for connection to an under-desk module or to a mains supply socket via an OE starter cable
Installation
- Simple to install in an 80 mm hole cutout in surface thicknesses from 8 mm to 40 mm
PixelARC is perfectly suited to desktops and workstations, breakout areas, meeting rooms, hotels, and other public spaces – installation of PixelARC is only limited by the imagination.
- Quick and Easy to Install
- PixelARC is simple to install in an 80 mm hole cutout in surface thicknesses of up to 35mm. Once installed PixelARC is convenient for either a full charge or a quick boost when you need it most!
- Qi certified – an international certification.
