WPF 13S /13/16 Geothermal Hydronic Heating Heat Pump

Name: WPF 13S /13/16 Geothermal Hydronic Heating Heat Pump
Brand: STIEBEL ELTRON

Auckland

280.4K profile views
61 saves

Save money while saving energy - the affordable WPF (S) basic series provides an ideal alternative to highly integrated geothermal heat pumps. Featuring top STIEBEL ELTRON quality, the WPF (S) basic is designed for easy installation. Thanks to its compact and timeless design, it fits nicely into your home without wasting valuable space. The WPF M range of geothermal hydronic heat pumps can be used with up to two controllers, making system control very easy. The modules can be matched, stage-by-stage, to your individual requirements, to deliver an energy supply solution for DHW and central heating.

Tags

central heating heat pumps heating geothermal hydronic heat pump geothermal heat pump

Product Details

Product: WPF 13S /13/16 Geothermal Hydronic Heating Heat Pump
Category: Heat Pumps
Sold by: STIEBEL ELTRON
Range: Heat Pumps
Brand: Stiebel Eltron

STIEBEL ELTRON is specified by

WPF 13S /13/16 Geothermal Hydronic Heating Heat Pump

Visit site

Featuring top STIEBEL ELTRON quality, the WPF (S) basic is designed for easy installation. Thanks to its compact and timeless design, it fits nicely into your home without wasting valuable space. The WPF M range of geothermal hydronic heat pumps can be used with up to two controllers, making system control very easy. The modules can be matched, stage-by-stage, to your individual requirements, to deliver an energy supply solution for DHW and central heating.

Save money while saving energy - the affordable WPF (S) basic series provides an ideal alternative to highly integrated geothermal heat pumps.

Specs

Model - WPF 13 S

Energy efficiency class - A++/A++
Output at B0/W35 (EN 14511) - 13.01 kW
Coefficient of performance at B0/W35 (EN 14511) - 4.75
Sound pressure level at a distance of 5 m - 28 dB(A)
Max. application limit on the heating side - 60° C
Height - 1319mm
Width - 598mm
Depth - 658mm
Weight - 171kg

Model - WPF 13

Energy efficiency class - A++/A++
Output at B0/W35 (EN 14511) - 10.31 kW
Coefficient of performance at B0/W35 (EN 14511) - 4.82
Sound pressure level at a distance of 5 m - 28 dB(A)
Max. application limit on the heating side - 65° C
Height - 1319mm
Width - 598mm
Depth - 658mm
Weight - 171kg

Model - WPF 16

Energy efficiency class - A++/A++
Output at B0/W35 (EN 14511) - 17.02 kW
Coefficient of performance at B0/W35 (EN 14511) - 4.54
Sound pressure level at a distance of 5 m - 31 dB(A)
Max. application limit on the heating side - 65° C
Height - 1319mm
Width - 598mm
Depth - 658mm
Weight - 171kg

Features

Geothermal hydronic heat pump installed indoors for underfloor and radiator heating
Compact design for easy placement in your home
Optimal energy use through efficient circulation pump
Timeless design
Highest European energy efficiency rating A++ for low energy bills
Extremely quiet operation thanks to advanced sound technology
Ideal to use in retrofits: up to 65° C flow temperature
