SD3 Modbus 100A

By Direct Control
Visit Website

The SD3 Modbus 100A is a high-precision energy metre designed to provide accurate measurement and monitoring of various electrical parametres. This three-phase, bi-directional metre is equipped with advanced features that make it ideal for a wide range of applications, including EV charger metreing, solar PV systems, energy storage systems, smart buildings, and more.

Details
  • Category
    Controllers, Home Automation
General
  • Country of origin
    China
  • Type of use
    Commercial and Residential
  • Installation
    Professional installation required
Features
  • Comprehensive Measurement Capabilities: The SD3 Modbus 100A accurately measures Kwh, Kvarh, KW, Kvar, KVA, PF, Hz, dmd, V, and A, providing a detailed analysis of your energy usage and electrical parameters.
  • Bi-Directional Measurement: It is capable of measuring both imported (IMP) and exported (EXP) energy, offering a complete view of energy flow.
  • Dual Pulse Outputs: Includes two pulse outputs for efficient data logging and control.
  • RS485 Modbus Communication: Ensures reliable and precise data transmission, supporting seamless integration with energy management systems.
  • Din Rail Mounting: Easily mountable on a standard 35mm DIN rail, simplifying installation.
  • 100A Direct Connect: Directly connects to 100A circuits, eliminating the need for additional current transformers.
  • Class 1 Accuracy: Exceeds Class 1 accuracy standards, ensuring high reliability and precision.
Applications
  • Electric Vehicle (EV) Charger Metering: Precisely monitor and manage energy consumption for EV charging stations.
  • Solar Photovoltaic (PV) Systems: Track energy production and optimise solar power system efficiency.
  • Energy Storage Systems: Ensure accurate measurement and management for battery storage installations.
  • Smart Buildings: Enhance energy efficiency and operational performance in smart building environments.
  • Residential, Industrial, and Commercial Use: Suitable for a broad range of settings, from homes to large-scale industrial facilities.
